封装：SOT-23-3（TO-236）
外壳：TO-236-3，SC-59，SOT-23-3
描述：
TVS DIODE 24V 55V SOT23-3
|
单向通道：1
双向通道：1
反向截止电压(典型值V)：24V
箝位电压最大值(V)：55V
峰值脉冲电流(/us)：5A（8/20µs）
峰值脉冲功率(W)：300W
|
string(51) "'dxtd','sxdt','dy_fxkg','dy_qw','dl_fzmc','gl_fzmc'"
SELECT COLUMN_NAME as bt,COLUMN_COMMENT as title FROM INFORMATION_SCHEMA.Columns WHERE ORDINAL_POSITION >=(SELECT ORDINAL_POSITION FROM INFORMATION_SCHEMA.Columns WHERE table_name='golon_tvs_ejg' AND table_schema='golon' and COLUMN_NAME='ms')+1 and ORDINAL_POSITION <=(SELECT ORDINAL_POSITION FROM INFORMATION_SCHEMA.Columns WHERE table_name='golon_tvs_ejg' AND table_schema='golon' and COLUMN_NAME='is_new_time') and table_name='golon_tvs_ejg' AND table_schema='golon' and COLUMN_NAME not in('tdxl','gysqjfz','lm','fz_wk','zzs','tag','wk_cc','zzs_old','zzs_new','ljzt','spq','sqp','is_rohs','bz','gys_id','gm_gys_id','xysl','cfkc','dj','price_addtime','zddgs','spq','moq''gl_zz','gl_dm','gl_dmtp','symbol','gl_vdd','gl_gnd','gl_jz','gl_bdm','gl_bdmsm','gl_kbc','gl_dmgx','pcbfzk_id','pcbfzk','jyid','cat_id','wl_num','admin_id','mpn_bm','ch_bm','lock_dm','is_use_cat_id','is_new_time','gl_zz','gl_pin') and COLUMN_NAME not in ('dxtd','sxdt','dy_fxkg','dy_qw','dl_fzmc','gl_fzmc') limit 8
系列：Automotive, AEC-Q101
类型：齐纳
电压 - 击穿（最小值）：26.7V
电源线路保护：无
应用：汽车级
不同频率时的电容：3.5pF @ 1MHz
工作温度：-55°C ~ 150°C（TJ）
安装类型：表面贴装型
|
|
|
